TerraForge TerraSpray X8 Plus

The TerraForge TerraSpray X8 Plus is a high-capacity agricultural octocopter designed for large-acre farms. Eight rotors deliver stable lift for heavy tanks, while the bright safety-orange body improves visibility during dawn and dusk operations. Its dual-pump manifold supports variable droplet sizes for herbicides, fungicides, and foliar feeds.

Specifications

• Material: Carbon-tube booms with reinforced composite hubs

• Dimensions: 220 cm unfolded diagonal; foldable for transport

• Power System: 8 × 32? props; dual ESC bus with redundancy

• Coverage Width: 8–10 m adjustable boom/nozzle layout

• Tank Capacity: 25 L; max flow 6 L/min; 18–22 min loaded flight

Features

• Octo-Redundancy: Safe return-to-home on single-motor failure

• Dual-Pump Manifold: Independent section control and pulse spraying

• Auto Refilling: Magnetic quick-dock for rapid turnarounds at the edge of field

• Multi-Sensor Suite: Front/rear obstacle radar and downward LiDAR

• Enterprise Planning: Cloud mission sharing, pilot logs, and coverage reports

• IP55 Protection: Sealed electronics for dust, rain, and chemical exposure

Maintenance

• Daily: Flush lines; inspect booms, clamps, and nozzle atomizers

• Weekly: Verify ESC temps; re-grease folding joints; run RTK check

• Annually: Replace main bearings and pump seals; structural torque audit

Warranty

• Airframe & Drive: 3 years

• Spray System & Electronics: 18 months
